Stationary Bin Lifter Round Forks

SERVOLiFT IBC (bin) handling lifters for every possible application. No matter what bin type or style, such as round or square we have the proven solution. We also specialize in high containment / high precision lifters required for today’s split butterfly valves and RTPs. As with all SERVOLiFT lifters we customize each system to meet your particular application. Over 2300 SERVOLiFT bin lifters are in operation today.

Typical Applications (loading):

• Tablet Presses,
• Encapsulators,
• Mixing tanks,
• Reactors/Compounding Tanks,
• Mills,
• High Shear Granulators,
• Media & Buffer Prep Tanks,

Design Capabilities:

• Lifting Capacity to 15,000 lbs,
• Lifting Heights to 60',
• Overhang (reach) to 12',
• Can be free standing, hung from the ceiling or attached to both ceiling and floor,
• Explosion proof for all classes and divisions,
• Cleanroom ready to Class 100,
• Full Washdown Stainless Steel 304 or 316L,
• Any level of finish,
• Controls offered from simple pneumatic to fully automated,
• PLC/HMI operation,
• 100% customizable for any possible application,
• Optional Load Cells can be installed into the arm system Shear Granulators a more proven or safe system.
