Robusto FL 120 GBK

Ergonomic drum-lifting, gripping and tilting systems for handling drums up to 120 Kg / 265 lbs in Chemical or Pharmaceutical production. Suitable for drums with a diameter of 14.5” – 20.5’. Entirely made of stainless steel 304. Glass bead-blasted surface. Tiltable lifter with a tilting manual lever. Explosion protection is available to CL 1, Div 1.

Dimensions & Data:

• Dimensions: 65.4” x 22.8” x 77.6” / gripper width 33.5”,
• Lifting height: 53.2”,

• Manual lifting function with toothed belt drive
,
• Min. lifting height, mid-gripper: 7.8" or 12.8",
• Max. lifting height, mid-gripper: 60” mm or 67.2”,
• 2 fixed load-bearing wheels, non marking GMP,
• 2 swivel wheels with locking brakes, non marking GMP,
• Load-bearing capacity: up to 120 kg
/ 265 Lbs,

Options:

• Ex-protected designs with ATEX/NEC approval,
• Battery-driven electrical lifting,
• Attachment options and special design elements on request,
• Also electro-polished surface, electrical gripping and tilting,
• Tilting by means of manual tilting gears,
• FDA-approved oil,
• Electrical sensor-controlled travelling drive,
• Other drum diameters and lifting heights are also available.
