Double Cone Lift Blender
The folding, spreading, and cascading action of the Double Cone Blender provides a rapid, homogeneous blending of dry and semi dry materials. The end over end revolving action, moving materials in and out of a restricted area results in a thorough intermeshed of the products into a uniform mix.
When required Double Cone Blenders can be equipped with a solids intensifier bar for disintegrating lumps or agglomerates and for dispersing minor ingredients. With the addition of a rotary union and liquid feed tube, the agitator assembly can incorporate minute quantities of finely dispersed mist through the agitator discs into the product mix.
For dispersion of viscous liquids, special spray nozzle assemblies can be fitted enabling precise control of droplet size with independent control of the solids intensifier bar.Batch working capacities range from 1 cubic foot to 250 cubic feet based on fill level of 55% of total volume.
Each blender design is customized to suit the customer's specific requirements.
For improved blend uniformity, special designs incorporating internal deflector cones, or angled shell bodies are available upon request.
Convertible models are available for the customer who does not have an immediate requirement for use of an agitator but has the possibility for future applications. This design includes a pre-machined blender idler shaft to accept bearing, seal assembly, and insertion of the agitator assembly. The idler shaft hub ends are supplied with stainless steel caps and a motor base plate is installed on the support frame for future installation of the agitator drive. bAt the time of conversion, the agitator assembly complete with bearing and seal assemblies, motor, V-belt drive, and guard are furnished for installation without disrupting the equipment.
